Parts:

1 ‘Lollipop’ main frame

2 Main Handle Front blade

3 Main Handle Rear blade

4 Handle grips L&R x2

5 Phone Plate

6 Phone Plate Key x2

7 Phone Plate key wedge x2

8 External Mic ring mount /2

9 Mic ring and holder

10 Ribs x12

11 Centre Boss used to secure ribs

12 Lavaliere Mic Perch


PREPARATION

As you remove parts from the panel, some may have rough edges which can be smoothed by gently rubbing the edge with sandpaper. See video on our website for demonstration. To fit parts together use sandpaper to lightly round the edges and reduce thickness if tight.
